Parameters:
Item |
Unit |
Parameter |
Model |
|
YF-X5 |
Cleaning Width |
mm |
520 |
Squeegee |
mm |
830 |
Brush Diameter |
mm |
500 |
Capacity |
m2/h |
2600 |
Water Tank |
L |
65 |
Sewage Tank |
L |
75 |
Working Time |
h |
3-4 |
Power |
V/AH |
24/100 |
Brush Motor |
w |
550 |
Vacuum Motor |
w |
500 |
Water Pump |
w |
120 |
Weight |
kg |
135 |
Dimension |
mm |
1300*830*1010 |
Packing Size |
mm |
1360*660*1220 |
Characteristics
1. Chassis Double-Layer Anti-Rust Primer: Electrostatic powder coating with secondary surface painting, anti-rust and anti-peeling. The coating process includes degreasing, grinding, applying putty, epoxy zinc-rich primer (with 40% zinc content), and plastic spraying (electrostatic powder coating). The final coating is hard and durable.
2. Vehicle Wiring Control: Designed by the Tongji Automotive Research Institute, using national standard wires, waterproof plugs, flame-retardant wire tubes, and well-known electrical components. Wires are stripped by a wire stripping machine. The vehicle wiring control is designed and manufactured according to passenger vehicle standards.
3. Standard High-Pressure Water Gun: Easier to clean with a high-pressure water gun.
4. Water Tank Material: Made of imported PE (modified material), produced with rotational molding technology, more environmentally friendly and resistant to fading outdoors.
5. Ergonomic Design: Features an ergonomic handle, silicone waterproof skirt, and 304 stainless steel fastening screws throughout the vehicle.
6. Foot Pedal Lifting Brush and Suction Pad: Frees your hands, allowing you to control water flow without bending over.
